BRAND | Calectro |
Product | UG-5-AFR-24V-ST2 |
Description | air duct smoke switch 24 V AC/DC |
Internal code | ONR4622222 |
Custom code | 85311030 |
Technical specification | 24 V AC/DC The Uniguard smoke detector is designed to detect smoke in ventilation ducts and combines a smoke detector with an adapter system, the pipe and housing being specially designed for optimal air flow through the smoke detector.The UG-5 can be installed on each side of the duct in four different positions: 0°, 90°, 180° and 270°. Patented. Comes complete with air duct removal pipe, 0.6 m length Power supply: 24 V AC/DC -15%, +10% Smoke detector type: UG-5-AFR-24V optical Max current consumption: 220 mA Operating temperature: -10°C to +55°C Max Humidity: 99% RH Air speed range: 1 to 20 m/s Approvals: VdS G213014, CE, pren-54-27 Smoke alarm release via remote reset Relay output: Potential free Smoke alarm relay: Two changeover contacts 250 V, 8A Service alarm: One changeover contact 250 V, 5 A System fault alarm: One changeover contact 250 V, 5 A Air speed alarm: One switching contact 250 V, 5 A LED on smoke detector: Green: Service alarm (contamination) red - smoke alarm LED on printed circuit board: Green: normal operation yellow - system error yellow - air speed alarm Adapter housing: ABS Protection class: IP54 |
Discover the superior quality and performance of the Calectro UG-5-AFR-24V-ST2 with Onrion LLC in Paraguay . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The UG-5-AFR-24V-ST2 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of UG-5-AFR-24V-ST2 :
At Onrion LLC , we offer the UG-5-AFR-24V-ST2 at competitive prices and with the fastest delivery times across Paraguay . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the UG-5-AFR-24V-ST2 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Calectro products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
