| BRAND | Ascon |
| Product | KX3-HCIRRD-E |
| Description | Controller series KX3, programmer with independent timer |
| Internal code | ONR3793061 |
| Weight | 1 |
| Technical specification | Dimensions 48 x 96 mm (1/8 DIN), depth 76 mm Front protection degree IP54, with gasket Double LED display: - Main Display: 4 digit, 3 dynamic colour red, green and amber h 15.5 mm - Secondary Display: 4 digit, green h 10 mm + 21 segments Bargraph Model: KX3-ABCDEFGHIJ A-N°: G-N°: (A) Model -: Controller T: Controller + Timer P: Controller + Timer + Programmer (B) Display -: 3 dynamic colours (C) Power supply L: 24 VAC/DC H: 100… 240 VAC (D) Input C: TC, RTD, mA, V, mV E: TC, NTC, PTC, mA, V, mV (E) OUT 1 R: Relay (SPDT) O: VDCxSSR I: 0/4… 20 mA isolated, 0/2… 10 V (F) OUT 2 R: Relay SPST 2A O: VDCxSSR M: Relay for Motorvalve driving -: Not available (G) OUT 3 R: Relay SPST O: VDCxSSR M: Relay for Motorvalve driving For Valve Motor Drive output, both OUT2 and OUT3 have to be present and ordered -: Not available (H) IN/OUT4 D: Digital Input or Digital Output or Tx supply (I) Serial communiction S: RS485 -: TTL Modubus (J) Terminals E: Plug-in type N: Plug-in type (fix part only) M: Spring type -: Fix screw type |
Discover the superior quality and performance of the Ascon KX3-HCIRRD-E with Onrion LLC in Paraguay . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The KX3-HCIRRD-E is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of KX3-HCIRRD-E :
At Onrion LLC , we offer the KX3-HCIRRD-E at competitive prices and with the fastest delivery times across Paraguay . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the KX3-HCIRRD-E ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Ascon products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
