BRAND | Indexator |
Product | 5006285 |
Description | Gripper rotator |
Internal code | ONR4020485 |
Custom code | 84122981 |
Technical specification | INDEXATOR gripper rotator GV-6 replaces 5006085 ⦁ Compact, lightweight yet durable rotator ⦁ Very durable construction - vane rotator with unique workmanship ⦁ Suitable for building material cranes, municipal vehicles, light forestry tractors, lightweight pulleys, rear trailers ⦁ 6,000 kg max. static load, 2,500 kg max. dynamic load ⦁ Torque of 1400 Nm at 200 bar ⦁ Low oil consumption 25 l/min ⦁ Compact and lightweight at just 44.9 kg ⦁ Top mount: 2 lugs with 80.5 mm spacing and 35 mm hole for stud ⦁ Bottom mount: 6-hole flange 173 mm diameter (6x17-173 mm) ⦁ Hydraulic connections at the top 4 x BSP 1/2" IG all on one side, one hose protection bracket ⦁ Hydraulic connections at the bottom 2 x BSP 1/2" IG in the shaft axially downwards and the same channel laterally (radially) in the flange 2 x BSP 1/2" with covers closed (please use a radial nipple set for connection, item no. 5212051 order) |
Discover the superior quality and performance of the Indexator 5006285 with Onrion LLC in Paraguay . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 5006285 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 5006285 :
At Onrion LLC , we offer the 5006285 at competitive prices and with the fastest delivery times across Paraguay . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the 5006285 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Indexator products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
