CFIA - 2 - MA.IP - 7H.T - ET - S Globtop

Buy CFIA - 2 - MA.IP - 7H.T - ET - S from Globtop in Paraguay

BRAND	Globtop
Product	CFIA - 2 - MA.IP - 7H.T - ET - S
Internal code	ONR4941119
Technical specification	GLOBTOP® CF series case, mod. CFIA in 316L stainless steel with indicator of open/closed position for rotary valves. ATEX Certification (BVI 19 ATEX 0006): Ex II 2 GD - Ex db IIC T6/T5 - Ex tb IIIC IP66/67 T85/T100°C (Tamb. from -40°C to +60/+80°C) - Cable entry: No. 3 3/4" npt-f - Terminal block: 12 terminals plus ground connection - Degree of protection: IP66/67/67M - Treatment: electropolishing - Position indicator: three-dimensional dome in red-green color - Shaft: namur coupling — Stainless steel material 3 16 In each case, n. 2 GO switch limit switches and n. 1 4÷20mA microprocessor transmitter with the following characteristics will be mounted: TRANSMITTER - Supply voltage: 10÷28.8 Vdc - Nominal current output: 4÷20 mA (for maximum range of variation; see diagnostic tab.1) - Current resolution: ± 4 µA (0.09° over 360°) and ± 15 µA (0.09° over 90°) - Calibration accuracy: ± 0.2% F.S. - Linearity: ± 0.5% F.S. + potentiometer linearity - Hysteresis: nothing - Repetitiveness: equal to the resolution of the potentiometer - Minimum/maximum span: 20°/330° assuming a maximum rotation of 360°. - Potentiometer ohmic value: 10 kΩ - Potentiometer power supply: 2.5Vdc (reference voltage internal to the board) - Temperature range: -40°C ÷ +85°C - Temperature coefficient: 2.5 µA/°C - Damping (63% of the instantaneous signal change from 4 to 20mA): 1.2 sec (default) Potentiometer - Resistive potentiometer from 0 ÷ 10KΩ with conductive plastic element (Specific model for the function of position transducer) - Potentiometer linearity: ≤± 0.5% maximum - Resolution: practically infinite - Absorbed power: 1W at 70°C - Working temperature: - 40°C ÷ + 125°C GO - SWITCH - passive type 70 series magnetic limit switch mod. 7H (without power supply and without reed contacts) - mechanical contact (snap action & dry contact): DPDT in palladium - silver - contact capacity: 3A at 120Vac, 1A at 24Vdc (resistive load) - 0.5A at 120Vdc (inductive load) - sensitive distance: 2.3 mm (with ferrous feedback) - differential (hysteresis): 0.5 mm (with ferrous feedback) - response time: 8 milliseconds - working temperature: see T.amb. of enclosure certification - case: stainless steel - seal: IP 66 (NEMA 5) - 105°C PVC insulated connecting conductors with output in axial position.

Discover the superior quality and performance of the Globtop CFIA - 2 - MA.IP - 7H.T - ET - S with Onrion LLC in Paraguay . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.

The CFIA - 2 - MA.IP - 7H.T - ET - S is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.

Key Features of CFIA - 2 - MA.IP - 7H.T - ET - S :

High Performance: Engineered to deliver exceptional results.
Durable Construction: Built with high-quality materials for long-lasting use.
Innovative Design: Incorporates the latest technology for enhanced efficiency.
Cost-Effective: Offers great value for money with competitive pricing.

At Onrion LLC , we offer the CFIA - 2 - MA.IP - 7H.T - ET - S at competitive prices and with the fastest delivery times across Paraguay . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.

Why Choose Onrion LLC ?

Expert Assistance: Get help from our knowledgeable team for all your product-related questions.
Competitive Prices: We offer some of the best prices in the market.
Fast Delivery: Benefit from our efficient delivery network for quick turnaround times.
Customer Satisfaction: Our commitment to customer service ensures a great buying experience.

Get Your Quote Today! Ready to enhance your operations with the CFIA - 2 - MA.IP - 7H.T - ET - S ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.

Important Notice: While we supply Globtop products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
