BRAND | Thermokon |
Product | AKF10+ TRV MR 250.06 |
Internal code | ONR4978449 |
Custom code | 90251900 |
Technical specification | 621632 AKF10+ TRV MultiRange 250.06 Channel/immersion sensor -50.. +160 °C — 0.. 5 V, 0.. 10 V 8 measurement ranges can be set on the transmitter (standard: 0.. +160 °C) Operating temperature range: housing -35.. +70 °C, sensor sleeve -50.. +160 °C Measurement insert with SI protection to protect against moisture and vibrations output: 0.. 10 V = Voltage supply: 15.. 24 V = (± 10%) or 24 V ~ (± 10%) Acid-resistant stainless steel sensor sleeve for aggressive media Ø=6 mm, installation length 250 mm, V4A USE-S impact and shatterproof housing with hinged cover (PC, pure white, IP65), 63x68x40 (LxWxH) Removable cable entry (M20 flex, replaceable) and removable plug terminal (max. 2.5 mm²) incl. mounting clip and mounting screws |
Discover the superior quality and performance of the Thermokon AKF10+ TRV MR 250.06 with Onrion LLC in Paraguay . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The AKF10+ TRV MR 250.06 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of AKF10+ TRV MR 250.06 :
At Onrion LLC , we offer the AKF10+ TRV MR 250.06 at competitive prices and with the fastest delivery times across Paraguay . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the AKF10+ TRV MR 250.06 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Thermokon products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
